Network Attached Digital to Analog Converter

Just plug NADAC into your network, and enjoy high resolution music up to DSD256 and PCM 384 kHz / 24 bit.

Available in two- and eight-channel configurations

Untitled-1

Available in two- and eight-channel configurations.

NADAC is available in two-channel and eight-channel configurations. The eight-channel NADAC may be set to two-channel mode at any time, for improved linearity, greater dynamic range and a lower noise floor.

Suggested retail price incl. VAT:

2-channel € 9.799,-

8-channel € 10.750,-

Ravenna

Ravenna

NADAC relies the open and published IP network technology Ravenna. Merging worked close together with the developers to enable extremely high PCM and DSD sample rates, rendering Ravenna the only logical choice for the professional and audiophile.

Extremely accurate clocking

High resistance to package loss

Unbelievably low latency

Read more

Untitled-1

Superb Specifications

nadac02

Superb specifications.

With NADACs extremely low distortion and noise, and unbelievably huge dynamic range, you’re now able to enjoy your high-resolution music with all of its musicality and emotional intention.

< 0.00022% THD+N

130 dB dynamic range

PCM 44.1 – 384 kHz / 24 bits

DSD 64fs – 256fs

Read more

Outputs

Balanced Analog Output

  • Connector: gold-plated male XLR
  • Impendance: 40 Ohms
  • Max output level: 18 dBu (6.1 Vrms)
  • Dynamic range: 130 dB(A)
  • THD+N @ 1 kHz: -113 dB (0.00022 %)

Unbalanced Analog Output

  • Connector: gold-plate RCA jacks
  • Impendance: 20 Ohms
  • Max output level: 8.8 dBu (2.1 Vrms)
  • Dynamic range: TBD
  • THD+N @ 1 kHz: TBD

Headphone

  • Connector: 3.5mm jack + 6mm jack
  • Impendance: 40 Ohms
  • Max output level: 20.8 dBu (2.1 Vrms)
  • Dynamic range: TBD
  • THD+N @ 1 kHz: TBD

Inputs

AES Input

  • Connector: gold-plated female XLR
  • Input impendance: 110 Ohms
  • Sample rate: 44.1 kHz – 192 kHz

S/PDIF Optical Input

  • Connector: TOSLink
  • Sample rate: 44.1 kHz – 96 kHz

S/PDIF Coaxial Input

  • Connector: gold-plated RCA jack
  • Input impendance: 75 Ohms
  • Sample rate: 44.1 kHz – 96 kHz

Network Input

  • Connector: Neutrik EtherCon RJ45
  • Input impendance: 75 Ohms
  • Sample rate: 44.1 kHz – 384 kHz, DSD64 – DSD256

Wordclock Input

  • Connector: BNC
  • Input impendance: 75 Ohms
  • Termination: 75 Ohms, software selectable
  • Sample rate: 44.1 kHz – 192 kHz

Misc

  • Enclosure material: Premium machined and anodized aluminium
  • Dimensions: 435 x 435 x 95 mm (W x D x H)
  • Weight: 11 kg
  • AC Voltage: 100 V – 240 V / 47-63 Hz (IEC socket)
  • DC Voltage: 10 V – 14 V (Hirose HR10A-7R-4S)
  • Power Consumption: < 30 W
  • Front panel display: OLED, 160 x 128 pixels, 16 bit colors

Testimonial

” The honesty of the Merging device simply makes it seem like it is playing music totally unconstrained by the electronics. ”

Hi-Fi+ read full review



” If I had to attribute a single descriptor to the inherent sonic signature of this DAC when handling DSD files, it would be … ”

Esoterica read full review
